Sony ZS-D10 Service Manual

48
ZS-D10
CD
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3663-873-A CD BOARD, COMPLETE
*******************
< CAPACITOR >
C701 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C702 1-126-947-11 ELECT 47uF 20% 10V
C703 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C704 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C705 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C706 1-126-960-11 ELECT 1uF 20% 50V
C707 1-115-156-11 CERAMIC CHIP 1uF 10V
C708 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C709 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C711 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C716 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C717 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C718 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C719 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C720 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C721 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C722 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C723 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C724 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C725 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C726 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C727 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C728 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C729 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C730 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C731 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C733 1-104-665-11 ELECT 100uF 20% 10V
C734 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C735 1-126-916-11 ELECT 1000uF 20% 6.3V
C736 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C740 1-126-935-11 ELECT 470uF 20% 10V
C741 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C742 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C743 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C744 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C745 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C746 1-104-665-11 ELECT 100uF 20% 10V
C751 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C754 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C755 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
NOTE:
•Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
< CONNECTOR >
CNP701 1-784-781-11 CONNECTOR, FFC 20P
* CNP702 1-784-736-11 CONNECTOR, FFC 14P
* CNP703 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< SHORT >
FB701 1-216-864-11 SHORT CHIP 0
< IC >
IC701 6-701-796-01 IC LC78646E-E
IC702 6-701-787-11 IC BA5826FP-E2
< SHORT >
JC703 1-216-864-11 SHORT CHIP 0
JC704 1-216-864-11 SHORT CHIP 0
JC705 1-216-864-11 SHORT CHIP 0
JC706 1-216-864-11 SHORT CHIP 0
JC707 1-216-864-11 SHORT CHIP 0
JC708 1-216-864-11 SHORT CHIP 0
JC709 1-216-864-11 SHORT CHIP 0
JC710 1-216-864-11 SHORT CHIP 0
JC711 1-216-864-11 SHORT CHIP 0
< RESISTOR >
L701 1-216-801-11 METAL CHIP 22 5% 1/10W
L706 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q701 8-729-054-57 TRANSISTOR KTN2907AS-RTK
< RESISTOR >
R702 1-216-833-11 METAL CHIP 10K 5% 1/10W
R703 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R704 1-216-833-11 METAL CHIP 10K 5% 1/10W
R706 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R707 1-216-797-11 METAL CHIP 10 5% 1/10W
R708 1-216-833-11 METAL CHIP 10K 5% 1/10W
R709 1-216-837-11 METAL CHIP 22K 5% 1/10W
R710 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R711 1-216-813-11 METAL CHIP 220 5% 1/10W
R712 1-216-809-11 METAL CHIP 100 5% 1/10W
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
•Abbreviation
CND : Canadian model
EE : East European model
IT : Italian model

Sony ZS-D10 Specifications

General

Equalizer	Yes
Sleep timer	No
Device type	Portable CD player
Product color	Silver
Preset stations quantity	40
Dimensions (WxDxH)	530 x 127 x 195 mm

Weight and Dimensions

Weight	2500 g
