Sophos APX Series Quick Start Guide

2Quick Start Guide APX Series Access Points
* Supports 15/16", 9/16", 3/8" ceiling tracks
** The displayed image is of APX 740 device. Other APX models may vary slightly.
What is included in the box
Device Images
*
: Front and Back
LED
ETH1 Port
LAN (PoE) Port
Console (RJ45) Port
Reset button
Access Point This Quick Start Guide
and Security Notes
2 screws
2 wall anchors for wall-mount
Mounting bracket for
wall and ceiling (T-bar)
*
4 screws to attach
bracket to back of AP

Sophos APX Series Specifications

General

Wi-Fi Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz, 5 GHz
MIMO	2x2
Ethernet Ports	1 or more Gigabit Ethernet ports
Power over Ethernet (PoE)	802.3at PoE+
Security	WPA3, WPA2, WPA, WEP, 802.1X, AES, TKIP
Management	Sophos Central
Mounting	Ceiling, wall
Operating Temperature	0°C to 40°C (32°F to 104°F)
Model	APX 320, APX 320X, APX 530, APX 740, APX 940, APX 530X
