INSTRUCTION AND SERVICE PARTS MANUAL - FREEZER CS 800, s/n F0176-00 - ALFRED & CO
F6
CS ICE CREAM FREEZERS
13-nov-97
FEATURES
CS100 CS200 CS400 CS800 CS1100 CS1500
OUTPUT ICE CREAM (min-max) l/h 20-100 40-200 80-400 140-780 200-1060 300-1500
REFRIGERATING POWER W 4.400 9.810 17.200 27.270 38.350 55.600
CONDENSING/EVAP. TEMPERATURE °C +30/-32.5
REFRIGERANT TYPE R22 / R404A / NH3
CYLINDER SURFACE m
2
0,08 0,16 0,29 0,48 0,59 0,80
CYLINDER INNER DIAM. mm 105 105 155 155 155 155
BLADES N° 3x1 3x2 3x4 3x5 3x7
COMPRESSOR MOTOR KW 2,2 5,5 11 18,5 22 37
DASHER MOTOR KW 3 4 7,5 11 15 22
DASHER SPEED RPM 340 340 300 300 300 300
PUMP MOTOR KW 0,55 0,55 0,75 0,75 0,75 0,75
MIX PUMP ( Std model ) Piston #1 ROTARY #2 ROTARY
MIX PUMP ( Optional ) #0 ROTARY
ICE CREAM PUMP ( If included ) #0 ROTARY #1 ROTARY #2 ROTARY
MAX AIR CONSUMPTION l/h 100 200 400 800 1.100 1.500
REQUIRED AIR PRESSURE bar 7
CONDENSER INLET / OUTLET 1" / 1" 1 1/4" / 11/2" 2" / 2"
CONDENSER WATER REQ. APP. l/h 1.600 3.300 7.600 9.500 13.000 30.000
REQUIRED WATER PRESSURE bar 4
SP000100 - 14/11/97
