NANO SERIES - M16 / M24
USER GUIDE
NANO SERIES - M16 / M24
USER GUIDE
®
M16 M24
Noise
Hum & noise <-80 dB @ 20 Hz~22 KHz A-weighted, 1 channel & main level: 0 dB, the other: minimum
Crosstalk
Crosstalk <-80 dB @ 0 dB 20 Hz~22 KHz A-weighted, main level: 0 dB, the other: minimum
Frequency Response
Mic/Line Input to any output, 20 Hz-20 kHz <1 dB <1 dB
THD + N
Mic sens. -30 dBu, +20 dBu at all outputs @ 1 kHz <0.006% <0.006%
CMRR
Typical @ max gain @ 1 kHz >80 dB >80 dB
Typical @ any gain @ 50 Hz >60 dB >60 dB
Input & Output Impedance
Mic Input 1.8 kΩ 1.8 kΩ
Line Input 23.6 kΩ 23.6 kΩ
Stereo Input 20 kΩ 20 kΩ
Mix, Aux and Insert Sends 120 Ω 120 Ω
Input & Output Levels
Mic Input max. level +20 dBu +20 dBu
Line Input max. level +30 dBu +30 dBu
Stereo Input max. level +30 dBu +30 dBu
Headphones (@ 200 Ω) 150 mW 150 mW
Compressor
Gain 0 - 9 dB 0 - 9 dB
Threshold
20 dB →↓5 dB 20 dB →↓5 dB
USB 2.0 (Standard B)
Inputs / Outputs 2-in, 2-out 2-in, 2-out
Bit Depth 16-bit 16-bit
Sampling rate 32 kHz / 44.1 kHz / 48 kHz 32 kHz / 44.1 kHz / 48 kHz
USB Player
Inputs / Outputs 2-in, 2-out 2-in, 2-out
Record sampling rate 44.1 kHz 44.1 kHz
Power Consumption
Mains voltage 100 V-240 VAC, 50/60 Hz, universal input 100 V-240 VAC, 50/60 Hz, universal input
Physical
Net weight 6.59 kg 9.18 kg
Gross weight 8.2 kg 11.2 kg
Dimensions 504.62 x 425.00 x 88.34 mm 724.62 x 425.00 x 88.34 mm
Specications
