SoundCraft Signature 10 User Manual

10, 12, 12MTK User Manual
1.3: SPECIFICATIONS
INTRODUCTION > SPECIFICATIONS
1.3: INTRODUCTION > SPECIFICATIONS
TYPICAL SPECIFICATIONS
• Frequency Response
- Mic / Line In to any Output: +/-1.5dB, 20Hz-20kHz
• T.H.D.
- Mono Mic Sensitivity -30dBu, Input level -16dBu,
+14dBu @ Mix output: < 0.002% @ 1kHz
- Stereo Mic Sensitivity -30dBu, Input level -16dBu,
+14dBu @ Mix output: < 0.007% @ 1kHz
• Noise
- Mono Mic Input E.I.N. (max gain): <-126dBu
(150Ωsource)
- Stereo Mic Input E.I.N. (max gain): <-124dBu
(150Ωsource)
• Crosstalk (@ 1kHz)
- Channel Mute: >-90dB
- Fader Cut-off (rel +10 mark): >-90dB
- Aux Send Pots Offness: >-82dB
EQ (Mono inputs)
- HF: 12kHz, +/-15dB
- MF (swept): 140Hz – 3kHz, +/-15dB
- LF: .60Hz, +/-15dB
EQ (Stereo inputs)
- HF: 12kHz, +/-15dB
- MF: 1kHz, +/-15dB
- LF: 60Hz, +/-15dB
Power Consumption
- Signature 10: <50VA
- Signature 12: <60VA
- Signature 12MTK: <70VA
Operating Conditions
- Temperature Range: 5°C to 40°C
Input & Output Levels
- Mic Input: +12.5dBu max
- Line Input: >+26dBu max
- Stereo Inputs: >+26dBu max
- Mix Output: +21.5dBu max
-Headphones(@150Ω):300mW
Input & Output Impedances
-MicInput:1.2kΩ
-Hi-ZInput:968kΩ
-LineInput:10kΩ
-StereoInput:21.5kΩ
-Outputs:150Ω(balanced),75Ω(unbalanced)
USB Audio (10, 12)
- Inputs/Outputs: 2-in, 2-out
- Bit Depth: 16-bit, 24-bit
- Sampling rate: 44.1kHz / 48kHz / 88.2kHz / 96kHz /
176.4kHz / 192kHz
Multi-channel USB Audio (12MTK)
- Inputs/Outputs: 14-in, 12-out
- Bit Depth: 16-bit, 24-bit
- Sampling rate: 44.1kHz / 48kHz
Net Weight
- Signature 10: 4.96kg
- Signature 12: 5.66kg
- Signature 12MTK: 5.86kg
Unit Dimensions (W × H × D)
- Signature 10: 490mm x 380mm x 210mm
- Signature 12: 490mm x 455mm x 210mm
- Signature 12MTK: 490mm x 455mm x 210mm

SoundCraft Signature 10 Specifications

General

Channels quantity	10 channels
Product color	Blue
USB 2.0 ports quantity	4

Weight and Dimensions

Depth	313 mm
Width	380 mm
Height	113 mm
Weight	4960 g
