SoundCraft Signature 10 User Manual

10, 12, 12MTK User Manual
4.2: STEREO INPUT
CONSOLE ROUTING > STEREO INPUT
4.2: STEREO INPUT ROUTING
There are two types of
Stereo input channel.
Thersttwostereo
input channels have
microphone inputs
and can be used as
mono input channels
(odd-numbered input)
if required.
The highest-numbered
Stereo input is a sum of
the line level R inputs
and the stereo USB
input (if present). This
is the playback channel
and works with the IN-
TERVAL MUTE function
for convenient 2-track
playback functionality.
Stereo input channels
have the same routing
options as mono input
channels. Aux bus
contributions from
stereo channels are
made from a sum of the
left and right signals.
Group (GRP 1 and 2)
bus contributions from
(Signature 12 and
12MTK only) are
balanced / panned left
and right to Group 1
and Group 2 respect-
vely. In other words -
fully left would be fully
Group 1.

SoundCraft Signature 10 Specifications

General

Channels quantity	10 channels
Product color	Blue
USB 2.0 ports quantity	4

Weight and Dimensions

Depth	313 mm
Width	380 mm
Height	113 mm
Weight	4960 g
