SoundCraft Signature 10 User Manual

10, 12, 12MTK User Manual
4.5: GROUP MASTER
CONSOLE ROUTING > GROUP MASTER
4.5: GROUP MASTER ROUTING
Signature 12 and 12MTK only. The Group Master Outputs are derived from the post fade, post pan
sum of input channels routed to the corresponding Group busses (1-2 switches).
The Group Masters can contribute to the Master Left/Right Bus.
A useful example of this in practise might be where a group of related input channels (drum mics,
backing singers, and so on) are mixed relative to each other, then routed to GRP 1-2 (but not to
MST). If the Group Masters are then in turn routed to the Master Left/Right output you can adjust the
level of the whole group within the main mix by using the Group 1 and 2 faders.

SoundCraft Signature 10 Specifications

General

Channels quantity	10 channels
Product color	Blue
USB 2.0 ports quantity	4

Weight and Dimensions

Depth	313 mm
Width	380 mm
Height	113 mm
Weight	4960 g
