SoundCraft Signature 10 User Manual

10, 12, 12MTK User Manual
4.1: MONO INPUT
CONSOLE ROUTING > MONO INPUT
4.1: MONO INPUT ROUTING
All mono input channels
have the choice of XLR
(mic) and Jack (Line)
balancedinputs;the
two highest numbered
mono channels have
Hi-Z input switches for
the line inputs while
channels 1 and 2
incorporate switchable
input limiters.
All Mono input channels
can contribute to Aux 1,
Aux 2, Aux 3/FX, MST
(Master Stereo), and
the Solo bus. On
Signature 12 and
12MTK consoles mono
input bus destinations
also include Group 1
and 2 (GRP 1, GRP 2).
Like the Master Stereo
bus contribution, the
Group contributions are
sent post-pan/balance
(Group 1 is left, Group
2 is Right).
On signature 10, input
channel routing to the
Master Stereo Bus is
permanent;on12and
12MTK it is switched.

SoundCraft Signature 10 Specifications

General

Channels quantity	10 channels
Product color	Blue
USB 2.0 ports quantity	4

Weight and Dimensions

Depth	313 mm
Width	380 mm
Height	113 mm
Weight	4960 g
