SoundCraft Signature 10 User Manual

10, 12, 12MTK User Manual
5.2: AUX MASTER OUTPUT
CHANNEL CONTROLS > AUX MASTER OUTPUT
5.2: AUX MASTER OUTPUT
The Aux Master Output channel determines the output level of a whole Aux mix (the sum of all
Aux contributions). That is, the Aux 1 Master controls the Aux 1 output level, which is the sum of
all Aux 1 contributions from the input channels.
AUXn PRE/POST
Globally switch Aux sources from input channels between pre- and post-fade
Determines whether the Aux mix is aected by the input channel fader positions or not. Note that the
Stereo Playback channel has independent pre/post switching for Aux 1 and 2.
AUXn MST
Adjust the level of the Aux mix output for the corresponding Aux bus
AFL
Route the signal to the Solo bus and mute any channels not routed to the Solo bus
With an AFL enabled, the headphone output source will switch to the Solo Bus. Please see section 6 for
more detail.

SoundCraft Signature 10 Specifications

General

Channels quantity	10 channels
Product color	Blue
USB 2.0 ports quantity	4

Weight and Dimensions

Depth	313 mm
Width	380 mm
Height	113 mm
Weight	4960 g
