SoundCraft Signature 10 User Manual

10, 12, 12MTK User Manual
7.2: SIGNATURE 12MTK USB
USB > SIGNATURE 12MTK
7.2: SIGNATURE 12MTK USB
USB I/O
A USB Standard-B Plug for USB data connection
The USB connector above the highest-numbered stereo channel is for audio data connection. Please note, the
USB Standard-A plug next to the PHANTOM POWER switch is for powering USB devices only (charging devices,
USB-powered lamps, and so on).
USB RTN
Press to use the USB return-path for this channel
The USB audio channel corresponding to the input channel number will be used instead of the normal channel
input. The red LED indicator on the button will light to show that the function is active.
NOTE: The analoue input to an input channel will ALWAYS be SENT via the corresponding USB audio channel, so
you can use a USB SEND > DAW > USB RTN path to insert DAW-based plug-ins into the mixer’s channel path.

SoundCraft Signature 10 Specifications

General

Channels quantity	10 channels
Product color	Blue
USB 2.0 ports quantity	4

Weight and Dimensions

Depth	313 mm
Width	380 mm
Height	113 mm
Weight	4960 g
