SOUNDMASTER DAB970 - Device Controls Overview; Front View Controls; Back View Connections

DAB970 / English Instruction Manual
3
LOCATION OF CONTROLS
FRONT VIEW
BACK VIEW
1
Display
7
MENU button
2
Remote Sensor
8
BACK / PAIR button
3
, VOL+ / VOL- knob
9
button
4
Disc tray
10
button
5
Navigate / OK knob
11
PLAY / PAUSE button
6
Source button
12
Eject button
13
Antenna socket
16
AUX IN jack
14
USB socket
17
DC input
15
Headphone jack
