#EMG2000 MAGNUM™ DC LED Lightbar
EMG2000-DC 10.15
11
BREAKOUT BOX FLASH PATTERNS AND CONNECTOR INSTRUCTIONS
BREAKOUT BOX HOOKUP:
Make sure the 24-pin connector and the RJ-45 connector are snapped in securely.
Follow the label for the wire color to connect to a 12Vdc source, which turns on that given light or lights.
Make sure your wire connections are secured and isolated from any other wire.
LED Module Flash Patterns
# Pattern Name Sequence fpm* fps**
1 Quint Alternating 70 1.18
2 Warp Alternating 350 5.88
3 Inter-Cycle Flash Alternating - -
4 Quad Flash Alternating 80 1.35
5 RoadRunner™ Alternating 115 1.92
6 RoadRunner™ Simultaneous 115 1.92
7 Slow Runner Alternating 70 1.16
8 Slow Runner Simultaneous 70 1.16
9 Q-Switch™ Variable - -
10 Single, Steady Burn Steady Burn 115 1.92
11 Quad, Steady Burn Steady Burn 80 1.35
12 Warp, Steady Burn Steady Burn 350 5.88
13 Nothing, Steady Burn Steady Burn - -
14 E-Pattern Single Flash Alternating 230 3.85
15 E-Pattern Double Flash Alternating 128 2.13
16 E-Pattern Single Flash Simultaneous 230 3.85
17 E-Pattern Double Flash Simultaneous 155 2.6
18 Warp 1,2,3,4 Variable - -
19 Warp 2,3,1 Variable - -
20 Warp 3,2,1 Variable - -
21 Steady Burn Steady Burn - -
Input Group Control Light Output Groups
Front Inboard 1 Red, Yellow
Front Inboard 2 Green
Front Inboard3 Blue
Rear Inboard 1 Red/Yellow/White
Rear Inboard 2 Green/White
Rear Inboard3 Blue/White
Take Down White, Orange
*fpm=Flashes per Minute
**fps=Flashes per Second
LED Take down & Alley Flash Pattern
1 RoadRunner™ Alternating 115 1.92
2 PowerPulse™ Alternating 180 3.00
3 Q-Switch™ Variable - -
4 ETM™ Simultaneous 214 3.57
5 Steady Burn Steady Burn - -
Directional Bar Warning Function Patterns
1 PowerPulse™ Alternating Center Out 180 3.00
2 PowerPulse™ Alternating Left/ Right 180 3.00
3 Quad Alternating Center Out 80 1.35
4 Warp Alternating Adjacent 3.50 5.88
5 2X Individual Sweep - -
6 Hyper Scan Pulsing + Sweep - -
7 Super Scan Dual Rate Pulse/ Alt - -
8 Power Flash Dual Rate Alt/ Pulse - -
9 Thunder and Lighting Random - -
10 Steady Burn Steady Burn - -
Split Arrow Bars Also Have The Following Multi-color Patterns
10 RoadRunner™ Alternating 115 1.92
11 Warp Adjacent 350 5.88
12 Warp Adjacent 350 5.88
13 Inter-Cycle Flash Adjacent - -
14 Inter-Cycle Flash Alternating - -
15 Inter-Cycle Flash Alternating - -
16 Inter-Cycle Flash Alternating - -
17 Inter-Cycle Flash Alternating - -
18 Steady Burn Steady Burn - -
Directional Bar Directional Function Patterns
For
Left, Center Out, & Right Sequences
1 Solid Arrow Plus, Slow Grow / Decay
2 Solid Arrow, Slow Solid
3 Individual Arrow, Fast Individual
4 Chaser Arrow, Fast 2X Individual
SWITCH SETTINGS
SW1 SW2 SW3 SW4 SW5 SW6 PURPOSE
OFF OFF OFF 8 WIRE ARROW CONTROL
OFF OFF ON NO ARROW
OFF ON OFF N/A
OFF ON ON 4 MOD ARROW
ON OFF OFF 5 MOD ARROW
ON OFF ON 6 MOD ARROW
ON ON OFF 7 MOD ARROW
ON ON ON 8 MOD ARROW
ON PASSENGER-SIDE EXIT
OFF DRIVER-SIDE EXIT
ON SPLIT-COLOR ARROW MODULES
OFF FULL ARROW MODULE
ON ENABLE WARNING FLASH ON BLUE/WHITE OUTPUT
OFF DISABLE WARNING FLASH ON BLUE/WHITE OUTPUT FOR STT FUNCTION
LIGHTBAR CONTROLLER CONNECTOR INSTRUCTIONS
* Front inboards have DOUBLE colored wires
