INSTALLATION PRECAUTIONS
Before you install the amplifier, investigate your car's layout very carefully. Take
special care when you work near the gas tank, fuel lines, hydraulic lines and electrical
wiring. Before making or breaking power connections in your system, disconnect
the vehicle battery. Confirm that your head unit or other equipment is turned off while
connecting the input jacks and speaker terminals. If you need to replace the power fuse,
replace it only with a fuse identical to that suggested by this manual. Using a fuse of a
different type or rating may result in damage to your audio system or your amplifier
which is not covered by warranty .
MOUNTING AMPLIFIER
1.Plan the installation of the amplifiers and find a suitable location with sufficient air
circulation.
2. Check the drawing below to mount the bottom amplifier.
Fig 5. Mount amplifier
7
CONNECTING THE AMPLIFIER
1.Select cable and fuse according to the following table.
2. Connect the amplifiers ground with 4 gauge or heavier cable to a close, bare metal
part of the frame or chassis. Use a nut and bolt, NOT a screw! The ground cable must be
at least the same size as the +12volt cable.
3. Connect the remote terminal to remote output of the head unit using 16 gauge (or
heavier) wire.
4. Connect the a 100A fuse holder within 18”(45cm) of the car battery, and run 4
gauge or heavier cable from this fuse to the amplifier.
5. Connect all the inputs with high-quality cables.
6. Insert 100A fuse(s) into the battery fuse holder(s).
