Soundstream SA 164 - Page 3

0
0
Side view
IO
\
MAlN FUSE
uL u
Underside View
4
1.
2.
3.
4.
5.
6.
7.
6.
9.
Key to Callouts
+12V - Connected to fuse or circuit breaker, then battery’s positive post.
Ground - Main ground connection. Bolt to a clean chassis ground in the
vehicle.
Remote - Remote turn-on input from the head unit. Accepts +12V.
LED - Indicates amplifier power on.
Speaker Outpot Connections - Channels 1 & 2
Input Level - Variable from IOOmV to 23.
Inputs - Right and left channel inputs; only right channel input used in
“Mono” mode.
[underside] Stereo/Bridged Mono Switch - Select “Mono” for bridged
operation (use only right channel input or stereo position for 2-channel
Stereo or Mixed Mono operation).
[underside] Amplifier Crossover Switch - Select low pass or full range
operation.
10. [underside] Main Fuse - Main power supply fuse. Replace only with same
fuse value.
