Soundstream SA 164 - SA-80 Diagram and Key to Callouts; Key to Callouts (SA-80)

SA.164
I
-
/
I
i HANDCRAFTED IN U.S.A.
Top View (partial)
67 8
9 10
Side View
.f-Y
i
/
/\
ii’
CHANNELS 1 & 2
LOW PAS m FULL RANGE
.14
15
\
MAIN FUSE
I- i
11
Underside View
6
1.
2.
3.
4.
5.
6.
7.
6.
9.
10.
11.
12.
13.
14.
15.
v to Callouts
+I 2V - Connected to fuse or circuit breaker, then battery’s positive post.
Ground - Main ground connection. Bolt to a clean chassis ground in the
vehicle.
Remote - Remote turn-on input from the head unit. Accepts +12V.
LED - Indicates amplifier power on.
Speaker Output Connections - Channels 1 & 2
Input Level - Channels 1 812; variable from IOOmV to 2.5’.
Inputs - Channels 1 & 2; right and lefl channel inputs; only right channel
input used in “Mono” mode.
Speaker Output Connections - Channels 3 & 4
Input Level - Channels 3 & 4; variable from IOOmV to 2.5V
Inputs - Channels 3 & 4; right and lefl channel inputs; only right channel
input used in “Mono” mode
[underside] Stereo/Bridged Mono/Internal Switch (ch 3 & 4) - Select
“Mono” for bridged operation (use only right channel input or stereo
position for 2-channel Stereo or Mixed Mono operation). “Internal” allows
you to use the inputs to channels 1 & 2 to feed channels 3 814.
[underside] Amplifier Crossover Switch - Channels 3 & 4; select high
pass or full range operation.
[underside] Stereo/Bridged Mono/Remote Switch - Channels 1 8 2;
select “Mono” for bridged operation (use only right channel input or stereo
position for 2-channel Stereo or Mixed Mono operation.
[underside] Amplifier Crossover Switch - Channels 1 & 2; select low
pass or full range operation.
[underside] Main Fuse - Main power supply fuse. Replace only with
same fuse value.
