33
Installer Setup
Auxiliary Output Programming By Temp
If TEMP is selected for the Aux Output, the following setup steps
will appear:
Aux Output Temp Source (Setup step 73) - Specifies what temperature
source will be monitored for controlling the programmable output.
The options are:
Thermostat - Temperature is monitored from the thermostat sensor.
Outdoor Sensor - Temperature is monitored from the Outdoor
temperature sensor.
Wired Remote - Temperature is monitored from a wired sensor
connected to the Remote Sensor terminals.
External - The Auxiliary Output is controlled from an external
accessory source.
Aux Output Trigger Point Temp (Setup step 74) - Specifies the temperature
from the above selected source above which the Aux Output is triggered. A
non-adjustable two degree deadband is applied to avoid frequent triggering.
The ‘N.O.’ (Normally Open) or ‘N.C.’ (Normally Closed) function (Setup Step 66)
can be altered to make the output trigger below the set temperature. Temps are
adjustable from 0 - 120 degrees Fahrenheit.
Press Fan To Clear All Messages (Setup step 93)
This feature allows the user to clear all current error messages from
the display.
Skyport (Setup step 83)
Set to ON to allow access to Skyport services or to OFF to not allow access to
Skyport services. (Wifi accessory is required) Visit https://source1.skyportcloud.
com/ for more information.
Local API (Setup step 84)
Set to ON to allow third-party software to interface with your thermostat.
Typically used with home automation set-ups. (Wifi accessory is required)
