If your machine is equipped with a rear roller instead of the two wheels, the regulation is
carried out by unthreading the split pins from the forks of the two front wheels and from
the two frame-supports of the roller, to proceed by using the spacers, as explained before
(see fig. 2).
To get uniformity on cut, after regulating as explained before
(by rear roller), be sure the machine results parallel to terrain.
Minimum cutting height possible (following the two types of regulation) is 2,5 cm; the maxi-
mum possible is 12 cm.
REAR ROLLER
FIG. 2
Pag.17
FRAME SUPPORT
