ATTACHING THE MACHINE TO THE
TRACTOR
The machines described in this manual do apply to any kind of tractor provided of universal
third hitch point.
The characteristics (length, diameter of the holes for the lifting pins) of the tractor’s lifting arms
depend on the type of tractor, therefore it is necessary to prepare the machine in order to con-
clude the attachment correctly.
Before attaching the machine to the tractor you must be sure that the engine is turned off, brakes
are locked and the ignition key is removed.
This operation must be made on a flat area as it is very dangerous.
Do not allow anyone between tractor and implement when the
engine is running.
Follow these instructions:
Connect the hitch of the drawbar to the tractor using a hitch pin and the hair clip pin (see
fig. 1)
LOWER
PLATES
FIG. 1
Pag.12
