Installation
9
www spe pv com. -.
5 3 Install the inverter.
( - - ), (1) Drill four screws holes in the chosen mounting location Picture 5 1 2
ensure the electric drill is vertical the wall when drilling holes an not shaking
the electric drill due to the inclined mounting.
Mounting position
Picture512 ( --)
175.00mm
power grid
Solar Panel
Inverter
Electrical connection diagram the Isolator and
Breaker are Suggested to install
（
）
