SOYO 1200W Grid User Manual

11
6.3 AC connecting pin
Please use the attach AC cable to connect the Inverter with power grid
As picture (6-3-1)and (6-3-2)
AC Cable Connection（--）631
（6-3-2）Done with the AC connection
Electrical Connection
▼Do not insert and extract any connectors
Under the charged state
Warning
Yellow--PE
Blue--N
Red--L
AC Connection Description.
