Electrical Connection
10
6. Electrical connectionand Test run
This mentioned how to connect the Inverter solar array and eletrical and test
run. Please read those steps,warning and matters need attention
As 6-2-1, this is the diagram of the connection.
,
6.2 connection step
6 1 Specification of Cable.
.Please note this before the installation
1200W
Solar Array
DC+
1000W 1500W
Please connect the inverter without AC and DC Voltage
The open circuit voltage of the solar array must be less
than the Inverter.
.
Warning
▼
▼
Connection diagram
Connection diagram (--)621
Grid-Tied Micro Inverter
DC Input
AC Output
Grid
Length of cable
3 meters are best or less
Solar Array
DC -
minimum wire diameter 10AWG（ ）
minimum wire diameter 10AWG（ ）
To Next Page
