Spa Electrics Atom - Page 17

• DO NOT OVERTIGHTEN SCREWS WHEN RE-ASSEMBLING
CABLE-GLAND COMPONENTS INTO NICHE.
• DO NOT USE POWER-TOOLS
• DO NOT ADD SEALANTS, GREASES OR ADHESIVES TO
CABLE OR CABLE-GLAND COMPONENTS AT ANY TIME.
• ENSURE ALL SURFACES ARE CLEAN AND DRY PRIOR TO
CABLE & CABLE-GLAND INSTALLATION
• DO NOT ASSEMBLE / DISASSEMBLE UNDERWATER
IMPORTANT NOTES
1000mm (MAX) *
AFTER CABLE
ADJUSTMENT
700mm *
(STANDARD)
NOTE
ALWAYS ENSURE POOL LIGHT CAN
BE RAISED ABOVE WATERLINE FOR
INSPECTION & SERVICING
* CABLE LENGTH
CABLE LENGTH MEASURED FROM
FRONT OF CLAMP RING TO PLUG’S
CABLE-ENTRY POINT
17
CABLE ADJUST / REMOVAL
