Ambulatory Blood Pressure Monitor 90217 Service Manual
5-4
Monitor displays -- EC04
Base Station report prints:
04 Measurement not completed within 110 seconds. Occasional EC04 messages may
result from excessive patient movement. Frequent EC04 messages would either
indicate an improperly placed cuff or a monitor malfunction, which requires service.
Monitor displays -- EC05
Base Station report prints:
15 Equipment malfunction. Return it to Spacelabs Medical for service.
25 Unit failed to initialize. Please re-initialize.
35 At least one of the blood pressure or time readings obtained before the event code
is erroneous. Interpret all readings with caution.
55 A) Measurement aborted because cuff pressure was too high.
B) Measurement aborted because measurement has taken longer than two minutes
to complete.
65 Equipment malfunction. Return unit for service.
75 Equipment malfunction. Return unit for service.
85 Equipment malfunction. Return unit for service.
95 Cuff pressure baseline out of bounds.
Monitor displays -- LLL
Base Station report prints:
16 Low battery prior to start of measurement.
26 Low main battery after measurement started.
Monitor displays -- EC08
Base Station report prints:
18 Too few data entries to accurately determine blood pressure.
28 Diastole above 200 mmHg.
38 Pulse pressure less than 16 mmHg.
Monitor displays -- EC09
Base Station report prints:
19 Hardware fault (valve open with pump turned ON).
29 Diastolic pressure value cannot be obtained from the data available.
39 Systolic pressure value cannot be obtained from the data available.
49 Mean arterial pressure value cannot be obtained from the data available.
59 Heart rate value cannot be obtained from the data available.
69 Heart rate value cannot be obtained from the data available.
