Symbols
The following list of international and safety symbols describes all symbols used on Spacelabs Medical
products. No one product contains every symbol.
Symbol Description Symbol Description
HELP Key Keyboard Connection
SPECIAL FUNCTIONS Key Mouse connection
RECORD Key START/STOP Key
NORMAL SCREEN Key START/STOP
MONITOR SETUP Key STOP or CANCEL Key
ALARMS Key CONTINUE Key
PREVIOUS MENU Key ENTER Key
ON — Power Connection to Mains
OFF — Power Disconnection from
Mains
ON Position for Push Button Power
Switch
OFF Position for Push Button Power
Switch
On Direction ON/OFF
Television; Video Display Video Output
ON — Part of the Instrument Only OFF — Part of the Instrument Only
