Ambulatory Blood Pressure Monitor 90217 Service Manual
2-7
Setup
Operational Tests
Conduct the following procedures to verify proper operation of the 90217 ABP Monitor.
Equipment Required
• 90219-02 system
• 90219-03 ABP Base Station software
• Type AA alkaline batteries (3)
• Cable, 90217 to PC, P/N 012-0097-xx (greater than -02)
• Setup for air leaks (refer to Air Leak Test on page 2-8)
• Analog manometer (optional)
• Stop watch or equivalent
• Battery spring insertion tool, P/N 003-0084-00
Visual Inspection
1 Check the display window and ensure that it is clear (free from scratches, contamination, etc.)
with the words SYS DIA appearing on the left side.
2 Verify that the front panel START/STOP button responds with a clear “snap” when pressed.
3 Inspect inside the battery compartment to ensure that the battery springs are clean and provide
a good electrical contact with the batteries.
4 Install the three AA batteries and verify that the battery door closes and latches properly.
To Next Page
