Ambulatory Blood Pressure Monitor 90217 Service Manual
7-5
Protective Earth Ground Functional Earth Ground
Replace Fuse Only as Marked Fuse
Power supply jack polarity.
(+ / - signs may be reversed)
Equipotentiality Terminal
Alternating Current Direct Current
Both Direct and Alternating Current AC/DC Input
Amperes Hertz
Volts Watts
IEC 601-1 Type B equipment. The
unit displaying this symbol contains
an adequate degree of protection
against electric shock.
Class II Equipment
IEC 601-1 Type BF equipment
which is defibrillator-proof. The unit
displaying this symbol contains an
F-type isolated (floating) patient-
applied part which contains an
adequate degree of protection
against electric shock, and is
defibrillator-proof.
IEC 601-1 Type BF equipment. The
unit displaying this symbol contains
an F-type isolated (floating) patient-
applied part providing an adequate
degree of protection against electric
shock.
IEC 601-1 Type CF equipment. The
unit displaying this symbol contains
an F-type isolated (floating) patient-
applied part providing a high degree
of protection against electric shock,
and is defibrillator-proof.
IEC 601-1 Type CF equipment. The
unit displaying this symbol contains
an F-type isolated (floating) patient-
applied part providing a high degree
of protection against electric shock.
Loop Filter Adult NIBP
Symbol Description Symbol Description
AHz
VW
To Next Page
