ASSEMBLEASSEMBLE
4.
Install
dispensing
door
4h
4g
4i
Insert dispensing door assembly into
cylinder, beater rod first, pushing
handle all the way up as you insert
Fit gasket into grooves on back of door, flat
side out; slide beater guide over beater
rod, with flanged edge against the door
Secure door assembly in a cross-
pattern using hand-screws (4)
Spaceman USA 6210 Training rev111918
