DISASSEMBLE
Remove draw valves (3), twisting while
removing to prevent damage
Remove O-rings (4) and H-ring (1) from
draw valves using O-ring removal tool
Rotate star caps (3) so that tabs are
accessible; snap off star caps
4.
Disassemble
dispensing door
4e
4f
4g
Spaceman USA Soft Serve Pump Training
rev042219
