SpacePak ESP-J - Fan Balancing - Constant Speed

30
STANDBY
SETUP
UNIT SETTINGS
FAN SETTINGS
DEFAULTS
MODEL
UNIT SIZ E
UNIT TYPE
REVERSE VALVE
SEC HW COIL
AUX 1
FAN
AFST
FAN BALANCING
H START T 80°F
C START T 70°F
ON DELAY 2M
OFF DELAY 2M
FAN DELAY
START TEMP
SYSTEM
ESP
WCS
2430JH, 24 30JV ,3642JH
3642JV,4860 JH, 4860 JV
ESP: HP OR AC
WCS: RCC, AC, OR HEAT
O [COOLING]
B [HEATING]
YES
NO (Default)
HEAT
COOL
HEAT-COOL
CONST SPEED
CONST PRESS
AFST TE MP 34°F
CONSTANT SPEED
CONSTANT PRESSURE
Y1: SPEED%
Y2: SPEED%
Y12: SPEED%
W1: SPEED%
W2: SPEED%
W12: SPEED%
G: SPEED%
HDRF: SPEED%
ERV: SPEED%
DFS: SPEED%
Y1: ST PRESS
Y2: ST PRESS
Y12: ST PRESS
W1: ST PRESS
W2: ST PRESS
W12: ST PRESS
G: ST PRESS
HDRF: ST PRESS
ERV: ST PRESS
DFS: ST PRESS
Y1% PRESS CFM
50 0.4 350
Y2% PRESS CFM
50 0.4 350
Y12% PRESS CFM
50 0.4 350
W1% PRESS CFM
50 0.4 350
W2% PRESS CFM
50 0.4 350
W12% PRESS CFM
50 0.4 350
G% PRE SS CFM
50 0.4 350
HDRF% PRESS CFM
50 0.4 350
ERV% PRESS CFM
50 0.4 350
DFS% PRESS CFM
50 0.4 350
Y1 SP PRESS CFM
1.2 0.51 350
Y2% SP PRESS CFM
1.2 0.5 1 350
Y12% SP PRESS CFM
1.2 0.51 350
W1% SP PRESS CFM
1.2 0.5 1 3 50
W2% SP PRESS CFM
1.2 0.51 350
W12% SP PRESS CFM
1.2 0.51 350
G% SP PRESS CFM
1.2 0.5 1 350
HDRF% SP PRESS CFM
1.2 0.51 350
ERV% SP PRESS CFM
1.2 0.51 350
DFS% SP PRESS CFM
1.2 0.51 350
FAN BALANCING – CONSTANT SPEED FAN BALANCING – CONSTANT PRESSURE
3 Sec “ESC” KEY HOLD DOWN TIME
Firmware versions 1.4 and lower
(upon startup of the unit, verify proper firmware version
before following this menu tree)
