H INSTALLING SHAFTS INTO BASE
Start Block
Shaft Stand
Shaft Stand








 





LEFT
RIGHT
FRONTBACK
Step 3: Place shafts and elevator into base.
Push shaft into holes on base until sturdy.
Attach Power Box Stand to the Power Box.
Firmly seat the posts from the Power Box in
the holes on the base.
Step 4: Attach Shaft Connector (90mm) to
Shafts K and N. Attach Shaft Connector (50mm)
to Shafts F and G.
