SPALDING AA6A1355 - Assemble the Wheels

Assemble the Base
12
A
ASSEMBLE THE WHEELS
1. Secure the wheel brackets (4) to the wheels (5) using the axles (6) and pushnuts (7). Install each
wheel assembly to the base (1) with a single bolt (8) and washer (9).
NOTE
Do not install both bolts onto the wheel assembly at this time. The back bolt will be installed during the strut
assembly.
#1
#8
#9
#4
#6
#5
#7
#7
NOTE
Use a scrap wood board to support the pushnut/axle from the end to install the second pushnut onto the axle.
