Elevator Assembly
18
D
INSTALL THE ELEVATOR ASSEMBLY
1. Check the three screws on the pre-
assembled handle (23) for tightness.
2. Insert the height adjustment tube (26)
into the handle pre-assembly (23) and
secure with bolts (29) and nuts (30).
#23
#30
#29
#26
3. Install the pre-assembled lift bracket (22) and reinforcement bracket (27) to the top pole (12) with
the carriage bolts (28) and nuts (20). Tighten the ange nuts (20) completely.
IMPORTANT
DO NOT OVERTIGHTEN.
#22
#12
#27
#20
#28
#22
