Assemble the Backboard
25
E
ATTACH THE ELEVATOR TUBE ASSEMBLY
8. Insert the bolt (37) through the left side of the upper elevator tube (31), then stretch the spring
(34) onto the bolt (37).
9. Insert the bolt (37) through the right side of the upper elevator tube (31) and secure with nut (39).
IMPORTANT
POSITION THE SPRING (34) AGAINST THE ELEVATOR TUBES.
#39
#31
#31
#34
#37
