Assemble the Base
16
C
INSTALL THE POLE ONTO THE BASE
3. Rotate the non-secured ends of
the base struts (2) to align with the
mounting holes in the base (1).
4. Secure the ends of the base struts (2)
to the base frame using bolts (18) and
lock washers (24).
IMPORTANT
TIGHTEN ALL COMPONENTS COMPLETELY.
#18
#2
#2
#1
#24
5. Secure the cover (21) to the base struts (2) using the bolts (22) and nuts (14).
#21
#22
#2
#14
#2
