Parts List
34
Item Qty Part No. Description Item Qty Part No. Description
1 1 600262 Base 27 1 202528 Pin, Actuator Assembly
2 2 908556 Strut, Pole to Base 28 1 901967 Cover Plate, Rim
3 1 205355 Drill Bit, 11/64 29 3 205809
Bolt, Hex Head, 1/2-13 x 10.25
Long
4 1 901789 Top Pole, Black 30 4 208251
Spacer, Plastic, 0.50 I.D. x 0.13
Long
5 1 901880 Middle Pole, Black 31 8 206340 Lock Nut, Hex 1/2-13
6 1 901390 Bottom Pole, Black 32 2 908375 Elevator Tube, Lower - Long
7 2 800332 Wheel Bracket
33
1 568091
Label, Height Adjustment &
Moving
8 2 600056 Wheel, 3.5” 1 FR568091
Label, Height Adjustment &
Moving, French*
9 1 10830601 Rod, Axle 34 1 Rim
10 2 203099 Nut, Ny-lock, 5/16-18 35 2 908374 Elevator Tube, Upper - Short
11 1 209096 Bolt, Hex, 1/2-13 x 4 Long 36 2 208261
Spacer, Plastic, 0.53 I.D. x 2.38
Long
12 1 203131
Bolt, Hex Head, 5/16-18 x 5.00
Long
37 1 203470
Washer, Flat, 0.625 I.D. x 1.5
O.D.
13 2 207550 Pushnut 38 1 600362 Cap, Pole Top
14 12 203100 Hex Flange Nut 5/16-18 39 2 209290 Screw, #10-0.394" Long
15 1 908415 Bracket, Pole Mount 40 2 900867 Triangle Plates
16 2 204846
Carriage Bolt, 5/16-18 x 4.50
Long
41 1 203617 Cap, Base, Black
17 1 60016401 Sleeve, Screw-Jack 42 1 209240 Reinforcement Bracket
18 6 203153
Bolt, Hex Head, 5/16-18 x 0.75
Long
43 1 Net
19 1 108848 Plate, Pole Mounting 44 1 900033 Bracket, Slam Jam
20 1 201518
Bolt, Hex Head, 5/16-18 x 2.75
Long
45 1 206048 Bolt, Tee, 3/8-16, 3.25 Long
21 1 60008601 Front Cover 46 1 200318
Bracket, Reinforcement, Slam
Jam
22 6 203738
Bolt, Carriage, 5/16-18 x 1.75
Long
47 1 208760 Spring, Rim
23 4 206665 Bolt, Hex Head, 1/2-13 x 2 Long 48 1 203795 Nut, Special, 3/8-16
24 8 203218 Washer, Flat, 5/16 49 1 208499
Spacer, 0.53 ID x 0.75 OD x 3.25
L
25 2 203679 Bolt, Hex Head, 3/8-16 x 2 Long 50 4 209145 Spacer, 0.5 ID x 0.98 OD x 1.64 L
26 4 208892
Bolt, Hex Flange,5/16-18 x 1.625
L
51 1 600165 Cap, Height Indicator
