SPALDING BC0105 - Page 5

Package Contents
5
KIT 1 – BASE ASSEMBLY – 209131
#24
#13
203153 hex head bolt 5/16 x 3/4
#18
13 Pushnut (x2) 18 Bolt, Hex Head, 5/16-18 x 0.75 L (x4) 24 Washer, Flat, 5/16 (x4)
KIT 2 – POLE TO BASE ASSEMBLY – 209132
203100
NUT, HEX FLANGE, 5/16-18
#14
#24
203099Hex Locknut (Nylon Insert) 5/16-18
#10
203153 hex head bolt 5/16 x 3/4
#18
208505
#22
#25
#12
10 Nut, Ny-lock, 5/16-18 (x1) 12 Bolt, Hex Head, 5/16-18 x 5.00 L (x1) 14 Hex Flange Nut 5/16-18 (x6)
18 Bolt, Hex Head, 5/16-18 x 0.75 L (x2) 22 Bolt, Carriage, 5/16-18 x 1.75 L (x6) 24 Washer, Flat, 5/16 (x4)
25 Bolt, Hex Head, 3/8-16 x 2 L (x2)
POLE TO BASE HARDWARE
#19
19 Plate, Bottom Pole Mounting (x1)
