Package Contents
7
BACKBOARD ASSEMBLY
#11
20157801
#56
20157901
#57
#40
#32
#54
#35
#38
#29
11 Bolt, Hex, 1/2-13x4 Long (x1) 29 Bolt, Hex Head, 1/2-13 x 10.25 L (x3) 32 Elevator Tube, Lower, Long (x2)
35 Elevator Tube, Upper, Short (x2) 38 Cap, Pole Top (x1) 40 Triangle Plates (x2)
54 Backboard (x1) 56 Board Pad, Left Section (x1) 57 Board Pad, Right Section (x1)
KIT 4 – BACKBOARD – 210503
203100
NUT, HEX FLANGE, 5/16-18
#14
#26
#45
#3
#60
#59
#58
3 Drill Bit, 11/64 (x1) 14 Hex Flange Nut 5/16-18 (x4) 26 Bolt, Hex-Flange, 5/16-18 x 1.625 L (x4)
45 Bolt, Tee, 3/8-16, 3.25 Long (x1) 58 Washer, Flat, 1/4 (x6) 59 Screw, 1/4 x 1.00” Long (x6)
60 Protector, Screw (x6)
