SPALDING E6A994 - Page 16

16
ID# M6611742 07/08
POLE TO BASE ASSEMBLY - HARDWARE IDENTIFIER KIT #2 Shown Full Scale
PARTS LIST - KIT #2
Item Qty. Part No. Description
10 1 203099 Nut, Ny-lock, 5/16-18
12 1 202662 Bolt, Hex Head, 5/16-18 x 4-1/2 Long
14 6 203100 Hex Flange Nut 5/16-18
45 2 203156 Bolt, Hex Head, 5/16-18 x 1” Long
47 6 208505 Carriage Bolt, 5/16-18 x 1.5” Long
49 1 108181 Plate, Pole Mounting
50 2 203679 Bolt, Hex Head, 3/8-16 x 2 Long
51 4 203218 Washer, Flat, 5/16
52 1 200516 Cover, Bolt End, Vinyl
#51 (4)
203099Hex Locknut (Nylon Insert) 5/16-18
#10 (1)
#52 (1)
#45 (2)
#50 (2)
#49 (1)
#12 (1)
203100
NUT, HEX FLANGE, 5/16-18
#14 (6)
#47 (6)
KIT #2
208505
