SPALDING E6A994 - Page 18

18
7.
Rotate non-secured ends of base struts (2) outward to mounting holes in base as shown.
Secure ends of base struts (2) to wheel bracket (7), as shown. Repeat for opposite side.
1
45
2
2
51
45
51
IMPORTANT!
DO NOT TIGHTEN
COMPLETELY
8.
Secure cover (28) to base struts (2) using bolts (47) and nuts (14) as shown.
14
47
28
2
14
14
47
47
IMPORTANT!
TIGHTEN ALL COMPONENTS
COMPLETELY (STEPS 6-8).
45
51
