SPALDING E6A994 - Page 19

19
#15 (1)
#42 (1)
#24 (1)
#25 (1)
#22 (2)
ELEVATOR ASSEMBLY - HARDWARE IDENTIFIER KIT #3 Shown Full Scale
KIT #3
ELEVATOR ASSEMBLY PARTS LIST - KIT #3
Item Qty. Part No. Description
11 2 203063 Nylon Insert Lock Nut, 3/8-16
14 3 203100 Hex Flange Nut 5/16-18
15 1 801100 Bracket, Pole Mount
16 2 203053 Carriage Bolt, 5/16-18 x 4 Long
17 4 203232 Washer, Flat, 3/4” O.D.
19 2 206360 Bolt, Hex Head, 3/8-16 x 2-5/8 Long
Item Qty. Part No. Description
20 2 600282 Spacer, Plastic Biscuit
21 2 204857 Spacer, Metal 1/2” O.D.x 1.44 Long
22 2 204859 Cover, Pin Slide
23 1 203038 Carriage Bolt, 5/16-18 x 2-3/4 Long
24 1 204850 Pin, Locking
25 1 204853 Lanyard, Black Coil
42 1 206990 Reinforcement Bracket
#19 (2)
#16 (2)
203100
NUT, HEX FLANGE, 5/16-18
#14 (3)
#20 (2)
#17 (4)
#11 (2)
Item #23 (1)
#21 (2)
Not Shown Full Scale
