Assemble the Elevator Adjustment
16
E
ASSEMBLE THE ELEVATOR ADJUSTMENT
3. Slide inner adjustment tube (39) into outer tube assembly (38) until it snaps in place about
midway inside the outer tube assembly (38).
#39
#39
#38
4. Attach the inner adjustment tube (39) to
pole mount bracket (27) using bolt (18)
and nut (13).
WARNING
TIGHTEN THE BOLT (18) IN THE LOCK
NUT (13) UNTIL IT IS FLUSH (EVEN) WITH
THE OUTER EDGE OF THE NUT.
#27
#39
#13
#18
