SPALDING SPA0350 - Assemble the Goal; ASSEMBLE THE GOAL

Assemble the Goal
20
Assemble the Goal
Required Parts: Completed Goal Assembly:
• Kit 4
• Kit 5
• Socket Wrench or Wrench
• Safety Glasses
NOTE
Peel protective lm from surface of acrylic backboard prior to use.
G
ASSEMBLE THE GOAL
1. Insert the T-bolt (33) through the Slam Jam bracket (32).
2. Secure the Slam Jam bracket (32) to the backboard using the bolts (14) and nuts (16).
#33
#14
#32
#16
