Page 22
— When obstruction or corners are encountered it may be necessary to manually rotate the
hose (See Fig. 7) to enable feed through that area. The rotation will cause the jetting nozzle
to jump over or around those areas. When it becomes necessary to manually rotate the
hose to clear obstructions, any rotations in one direction must be followed by an equal
number in the opposite direction to prevent kinks from building in the hose.
— At times, it will be necessary to move the hose slightly in and out of the drain line to assist
the jetting nozzle in clearing stubborn clogs, obstructions, or tight corners (See Fig. 8).
Fig. 7 Fig. 8
When Obstruction Are Encountered
1/4” Drain Hose
The 1/4” hose and nozzle may be used to clean smaller diameter lines. Attach the 1/4” hose to the forward
end of the wash down gun as described above.
Use the 1/4” drain hose on lines 2” - 4” similar to the reel hose. Again, use care not to discharge water
unless the hose is in the pipe. On inside lines, use short bursts of the gun to limit water backup.
If 50’, 75’ or 100’ 1/4” hoses are used with the reel hose, the pressure gauge may read more than 2800
psi. Adjust engine speed to reduce to desired pressure to avoid engine overheat.
pp
pp
p
!
Standard Equipment Optional Equipment
Part # Description Part # Description
77719400 1/4" X 50' Hose 77719500 1/4" X 75' Hose
77708700 1/4" X 100' Hose
