Spartan Tool 758 - 758 Pump Parts List; 758 Pump Torque Specifications

Page 46
758 Pump Parts List
758 Pump Torque Specifications
Part
Number
Description
1
75800505
Crankcase
2
75800506
Oil Filler Cap
3
75800507
O-Ring, Filler Cap
4
75800508
Cover, Crankcase
5
75800509
O-Ring, Crankcase Cover
8
75800510
Oil Dip Stick
9
75800511
O-Ring, Dip Stick
10
75800512
Screw, Crankcase Cover
11
75800513
Spring Washer
12
75800514
Oil Drain Plug
13
75800515
Gasket, Oil Drain Plug
14
75800516
Bearing Cover
15
75800517
Seal, Crankshaft
16
75800518
O-Ring, Bearing Cover
17 75800519 Hex Screw, Bearing Cover
20
75800520
Rolling Bearing, Tapered
20A
75800521
Shim
21
75800522
Shaft Protector
22
75800523
Crankshaft
23
75800524
Key
24
75800525
Connecting Rod
24A&B 75800526 Hex Screw w/Washer, Conn.
Rod
25
75800527
Crosshead Complete
28
75800528
Crosshead Pin
29A
75800529
Centering Sleeve
29B
75800530
Ceramic Plunger, 24mm
29C
75800531
Bolt, Sold only w/#07258
29D
75800532
Seal Washer
30
75800533
Flinger
31
75800534
Crankcase Oil Seal
Item #
Part
Number
Description
35A
75800535
Rear Support Ring
35B
75800536
Rear V-Sleeve
35C
75800537
Rear Pressure Ring
36
75800538
Snap Ring
39
75800539
Pressure Ring
40
75800540
V-Sleeve
41
75800541
Support Ring
41A
75800542
Spacer
42
75800543
Tension Spring
42A
75800544
Tension Plug
42B
75800545
O-Ring
43
75800546
Manifold Head
43A
75800547
Plug
43B
75800548
Plug
44 75800549 Valve Seat
44A
75800550
O-Ring, Valve Seat
45
75800551
Valve Plate
46
75800552
Valve Spring
47
75800553
Spring Retainer, Discharge
48
75800554
Plug, SS
48A
75800555
O-Ring Plug
49
49A
75800556
75800557
Stud, Manifold
Shim, Stud
50
75800558
Nut, Manifold Stud
50A
75800559
Spring Washer
51
75800560
Spacer
52
75800561
Valve Housing
52A
75800562
Spacer Ring
53
75800563
O-Ring
53A
75800564
O-Ring
54
75800565
Spring Retainer, Inlet
Item #
Item # Part # Description Torque Amount
17 75800519 Hex Screw, Bearing Cover 125 in. - lbs.
24A 75800526 Hex Screw, connecting Rod 250 in. - lbs.
29C 75800531 Bolt, Plunger 300 in. - lbs.
50
75800558
Nut, Manifold Stud
700 in. - lbs.
