Page 49
Air Foot Switch
Item # Qty Part # Description
1 1 72706400 Decal, Untrained Personnel
2 2 77763500 Decal, Crank
3 1 77740300 Decal, Clamp
4 1 77749500 Decal, Hitch Coupler
5 1 77766300 Label, Danger "No Smoking"
6 4 75800100 Decal, Spartan 758
7 2 77739800 Decal, Caution Rear Reel
8 1 77739900 Decal, Warning Rear
9 1 75815400 Decal, Spartan
10 1 72707800 Decal, Warning HP Jet
11 1 73817800 Decal, "On" "Off"
12 1 75800200 Decal, Disengage/Engage
13 2 73817400 USA Label
14 1 75814100 Decal, Hold in to Start
15 1 75814200 Decal, Hose In
16 1 75815100 Decal, Gasoline Only
17 1 75814300 Decal, Spartan 758
18 1 75813900 Decal, Choke
19 1 75814000 Decal, Throttle
20 1 58546301 Decal, Battery
21
1
73817200
Decal, Caution
758 Decal Package - 75814400
Item
Number Part Number Req'd Description
ASP44055500 1 Air Foot Switch Complete
without Coupler (3, 4)
ASP04577200 1 Air Foot Switch
(Complete as Shown)
1 ASP04576900 1
Pressure Transmitter
2 ASP04577100 1 Air Hose
3 ASP04576700 1
Brasshose Barb
4 ASP04576600 1
Brass Coupler
5 ASP04652700 2
Crimp Type Hose Clamp
