Page 23
Wash Down Kit - 73817300
Note: To use wash-down gun do the following:
1 Turn reel supply valve “off” (down).
2 Connect wash-down gun hose to end of 250 ft hose.
3 Start unit and operate wash-down gun with reel supply valve “on” (up).
The wash down gun is used to control the spray lance and the 1/4” drain hose. The lance is attached by pulling
back on the ring of the guns quick connect fitting. Insert adapter nipple of lance (or 1/4” hose) until ring can slide
back to original position. The lance is equipped with a spray nozzle for general use.
Caution: Under no circumstances should you ever operate the wash down gun in the direction
of any other person(s). To do so may cause serious damage to eyes or other bodily tissue and
may even cause death!
Contents of Kit: 1/4” x 50’ hose, lance assembly, 1/4” nozzle, hand gun.
The mobile hose reel is used for remote use and control of the sewer hose. 400’ total length of hose is the
practical maximum with the 250’ or 150’ length on the machine reel and the balance on the mobile reel.
To use, attach the machine reel hose to the valve of the mobile reel. Attach nozzle to mobile reel hose and
make sure the mobile reel valve is off (handle perpendicular to valve body). Start jet as usual and open
machine hose reel valve.
Now move the mobile reel to the pipe opening and use as before, using the mobile valve to
control water flow (put hose in pipe before opening valve). To rewind hose, stand on front plate
and use crank provided.
!
Mobile Hose Reel - 73816800 (Optional)
