YOUTH SKATES
To watch the How-To video, visit sparxhockey.com/loadyouth.
Before loading a youth skate of size 12 or smaller, Youth Skate
Adapters must be installed onto each Protective Slot Cover. On the
adapter, locate the Upper Anchor Tab (A) on the top of the adapter
and then the Lower Anchor Tab (B) on the bottom.
Below is a cross-sectioned Protective Slot Cover. Locate the
recessed slot (C) and the tab cut out (D) on the Protective Slot
Cover Switch (E).
1 INSTALL YOUTH SKATE ADAPTERS
Press the Upper Anchor Tab (A in figure above) into the tab
cut out (C in figure above). Once it is in, rotate and press down
firmly on the bottom of the Youth Skate Adapter until the
Lower Anchor Tab clicks in place.
B
D
E
A
C
2
1
1 INSTALL THE GOALIE RISERS
Align the Anchor Pins of the Goalie Risers to the Anchor Slots
of the Skate Clamp. Once aligned, press down firmly until you
feel the Goalie Risers snap into place.
2 CONTINUE THE SHARPENING PROCESS
Refer to “Loading a Skate” in the Operation section of the
manual. When adjusting the Grinding Ring Height, refer the
graphic in step 3.
3 ADJUST THE GRINDING RING HEIGHT
Refer to “Adjusting the Grinding Ring Height” in the Operation
section of the manual using the figure below as your guide
where the desired contact point is A, contact point B is too
high and contact point C is too low.
5 CONTINUE THE SHARPENING PROCESS
Refer to “Sharpening Skates” in the Operation section
of the manual.
6 REMOVE THE GOALIE RISERS
Pull up on each end of the Goalie Risers to remove from the
Skate Clamp.
A
B
C
A
