Power Output/Channel (RMS, two channels driven into 8 Ohms) 80 Watts, 20Hz to 20kHz
THD (at rated power) <0.007%
Power/Channel (RMS, 2 channels driven into 4 Ohms) 125 Watts <0.1% @ 1kHz
Damping Factor > 100
Input Sensitivity (For rated power @ max VC) 220 mV Line IN, 2.0mV Phono IN
Input Impedance (Source Inputs) 11 K Ohms Line IN, >20 k Ohms Phono IN
Input Overload (Source Inputs) > 7 V Line IN, >110 mV Phono IN
Output Voltage @ Pre-Outs (w/220 mV @ Source Inputs) 1.25V, VC Setting, VC Max.
Output Impedance (Pre-Outs) < 300 Ohms
Frequency Response (@ 1 Watt @ 8 Ohms) 10 Hz to 80 kHz ± 1.5 dB
Channel Separation > 50 dB @ 10 kHz
Cross Talk Between Sources > 80 dB @ 10 kHz
S/N Ratio (Re: Rated Output, IEC A, Line Inputs Shorted) > 100 dB (VC 20 dB below FCW)
S/N Ratio (Re: Rated Output, IEC A, Phono Inputs Shorted) > 90 dB (VC 20 dB below FCW)
Bass Control Range ± 10 dB @ 100 Hz
Treble Control Range ± 10 dB @ 10 kHz
Signal Format Composite
Bandwidth (Outputs 75 Ohms Terminated) 10 Hz to 10 MHz ± 1dB
Input/Output Levels (I/O’s 75 Ohms Terminated) 1.0V p-p ± 5%
Input/Output Impedance 75 Ohms, unbalanced
Tuning Range 87.5 to 108.0 MHz
Usable Sensitivity (IHF, 98.1 MHz) 10 dBf Mono
Sensitivity (50 dB quieting, 98.1 MHz) 17 dBf Mono, 35 dBf Stereo
S/N Ratio (65 dBf, 98.1 MHz) 75 dB Mono, 72 dB Stereo
Freq. Response (Mono or Stereo) 20 Hz to 15 kHz ± 3 dB
Separation (@ 1 kHz, 65 dBf) > 40 dB
THD (1 kHz, 65 dBf, 98.1 MHz) 0.2% Mono, 0.4% Stereo
Capture Ratio (45 dBf) 2.0 dB
AM Rejection Ratio 50 dB
Alternate Channel Selectivity 70 dB
Tuning Range 520 to 1720 kHz
Sensitivity (20 dB Quieting, 1000kHz loop antenna) 500 mV/m
Selectivity (@ S/N 20dB, ± 10 kHz) 30 dB
S/N Ratio (400 Hz, 10 mV/m Input @ 1000 kHz, 30% Mod.) 45 dB
THD (400 Hz, 10 mV/m Input @ 1000 kHz, 30% Mod.) 0.8%
Selectivity ± 10 kHz, >25dB
Image Rejection (1400 kHz) 34 dB
