SP. A
1 - Vital 710 Stereo A/V Receiver
1 - Vital 710 IR Remote Control
2 - AAA Batteries
1 - FM Indoor Antenna
1 - AM Loop Antenna
1 - Front Panel Jack Cover
1 - Vital 710 Installation Instructions
80W Continuous x 2 Channels @ 8Ω; 20Hz - 20kHz;
<0.07% THD
125W RMS x 2 Channels @ 4Ω; 20Hz - 20kHz; <0.1% THD
@ 1kHz
AM/FM Stereo Tuner with 30 Channel Preset Memory
Moving-Magnet Phono
CD
Tape Monitor IN/OUT Loop
Pre-OUT/Main IN Loop
Video 1 IN/OUT
Video 2
Video 3 (Front and Rear Panel - selectable)
Speaker A, B, A+B
Tape Monitor OUT (line level audio)
Video 1 OUT (line level audio/composite video)
Sub A full band mono line level audio/15VDC Control
OUT
Sub B full band mono line level audio/15VDC Control
OUT
Headphone Jack
Sleep Timer
Large, clear uro-display
Dimmer for Front Panel Display Dim, OFF
Discrete ON/OFF Commands
Power ON from source select
Direct Numeric Tuning
Direct Numeric Preset Select
Manual Tuning
Volume/Mute
Speaker A/B Select
Dimmer
Sleep Timer
