Specialized Enduro Comp - 5.2. Pivot Assembly: Main Pivot

12
AA: MAIN PIVOT BOLT
M12 x 6 L
Z: MAIN PIVOT AXLE
15 OD x 82.9 L
 Grease, then insert the main pivot axle Z into the frame.
 Thread the non-drive side main pivot bolt AA into the axle. Torque the main pivot bolt to
160 in-lbf / 18 Nm.
BB: MAIN PIVOT
EXPANDER ASSEMBLY
M6 x 30 L
 Grease, then thread the expander assembly BB into the main pivot axle and torque the bolt
to 62 in-lbf / 7 Nm.
